Eigenschaften
FPGA
Lattice CertusPro-NX LFCPNX-100-7LFG672C device
RAM/Speicher
2 x 32 MByte RPC DRAM
32 MByte QSPI Flash Speicher
EEPROM
On Board
8 x LEDs (8 user)
5 x push button
1 x 4 Positionen Dip-Schalter
micro USB 2.0 (JTAG+UART)
micro USB 3.0 (FT601)
FMC Anschluss
PCIe x4 Edge Anschluss
SFP+ Anschluss
Schnittstelle
1 x CRUVI HS
1 x CRUVI LS
CSI-2 (Camera Serial Interface 2)
SFP+ (SGMII Interface)
FMC (34 LA diff pairs + 4 DP lanes)
PCIe x4
USB 3.0 (FT601)
Spannungsversorgung
PCIe- oder Stromanschluss
Größe
PCIe Formfaktor
107 x 168 mm
